Loading Bay Lifts Built for Modern Logistics
Warehouses, logistics centres and industrial facilities require efficient loading and unloading operations, where uptime and workflow continuity have a direct impact on productivity. A TRANSLYFT loading bay lift is engineered to connect vehicle loading bays and internal transport systems safely and efficiently, while moving huge items precisely and smoothly.
When looking for some sort of levelling solutions it is often a choice between traditional dock levelers and a loading bay lift. The difference is that a dock leveller only compensates for minor height differences and a loading bay lift provides full vertical movement. The loading bay lift creates a far more flexible solution when working with varying truck heights, containers, roll cages, pallets, and goods handling equipment is required. The result is faster loading operations, improved ergonomics, and a safer working environment.
Because every workflow is different, all TRANSLYFT loading bay lifts are customised to the application and operational requirements. We understand that every lift is unique, and our solutions are developed to support not only reliability and efficiency, but also the future readiness of your workflow.
Detailed Specifications
TRANSLYFT loading bay lifts are suitable for a variety of industrial situations and can be customized to suit a wide range of applications depending on the kind of load, traffic volume and installation conditions.
Typical capacities range from 1,000 kg to 6,000 kg and travel heights from 550 mm to 2,000 mm give the ability to move seamlessly between numerous vehicle and dock levels. The size of the platform can be adapted to the application, with lengths from 900 mm to 5,000 mm and widths from 650 mm to 3,000 mm.
Every loading bay lift is built on a robust hydraulic scissor lift construction designed for high stability and long-lasting life.
A Translyft loading bay is always equipped with safety trip bars, mechanical maintenance locks and hose burst valves. You can get further safety features such as:
- Anti slip platform surfaces
- Rails and gates
- Net/chain mesh, bellow, or roller curtains
- Beacon and sound
For specialised industries and demanding production environments, TRANSLYFT also offers multiple material and design variants including:
- Stainless steel solutions for corrosive environments
- Galvanized steel for outdoor installations
- ATEX approved solutions for explosive atmospheres
- Painted steel for standard industrial applications
